The Imperial System 16 Single Bracket
Starter Kit for Tables 4'x5' & Smaller
(6 Pieces)
Item no.: US16001STARTERKIT
The Imperial System 16 Single Bracket
Starter Kit for Tables 4'x5' & Smaller
(6 Pieces)
Item no.: US16001STARTERKIT
US160830
Quantity: 1
Shipping / Lifting Bracket with Fastening Plate
The Siegmund Shipping / Lifting Bracket with Fastening Plate is is the Best Solution to Quickly and Safely Transport Heavy Siegmund Parts. It is Used to Move Welding Tables and Other Heavy Siegmund Elements Safely and Easily.
Please consider following safety instructions:
1. Ring nuts should be completely bolted.
2. Ring nuts should bear flat and completely on support surface.
3. Length of mating thread has to be sufficient.
4. Lateral pull should be avoided.
- Height: 1"
- Weight: 3.7 lbs.
- Width: 3-15/16"
- Length: 3-15/16"
- Load Capacity: 1,540 lbs. Capacity
US160511
Quantity: 4
Short Fast Clamping Bolt(Burnished)
The Bolt Without Slot is Particularly Suitable for Clamping the Entire Siegmund Range. The Fast Clamping Bolt with Twist lock is the Ideal Connecting Element Between Siegmund Components.
- Length: 2.08"
- Weight: 0.17 lbs.
- Tensile Force: 10 kN
- Shearing Force: 55 kN
- Diameter: 16mm
- Material Type: Burnished
-Tightening Torque Steel: 10 Nm
- Tightening Torque Aluminum: 2.5 Nm
US000810
Quantity: 1
Ground Connection Comfort
Ground Connection, guarantees 100% contact to the welding table, therefore no overheating is possible. Simple installation by fastening it in a system borehole. This Ground Connection is for structural welding only. Not recommended for thin materials (i.e. Sheet Metal).
This may not work for all applications.
- Weight: 2 Ibs.
- Load up to 500 ampere
- Cable cross section: 0.109 - 0.147 square inch
