(Image shown is an example setup using a Siegmund System 16 Imperial Welding Table and accessories. Table and accessories are not included and sold separately.)
The System 28 Welding Table Imperial Basic Series was created with Heavy Duty Applications in Mind.
All System 28 Professional Extreme tables feature the latest upgrades in aesthetics, versatility, and durability.
Our Double Hardened Tables are constructed from through hardened steel before undergoing a Plasma Nitride treatment to provide you with a table of superior quality and performance.
Items Included in Bundle #US288215.XD7
for the Siegmund System 28 Basic Welding Tables 46 Piece Bundle
Get started right with your new welding table, or easily extend the capabilities of your current welding tables by purchasing a Set of Tooling dedicated to 28mm (1.10") Bore Holed Siegmund Imperial Series Welding Tables.
Accessories Included in
Set #5
for the Siegmund System 16 Welding Tables
(117 Pieces)
Total Weight of Set: 245 lbs.
Get started right with your new welding table, or easily extend the capabilities of your current welding tables by purchasing a Set of Tooling dedicated to 16mm (0.63") Bore Holed Siegmund Welding Tables.
Items Included
in Bundle #US288215.XD7
for the Siegmund System 28 Imperial Series Welding Tables
(46 Piece Bundle)
Get started right with your new welding table, or easily extend the capabilities of your current welding tables by purchasing a Set of Tooling dedicated to 28mm (1.10") Bore Holed Siegmund Imperial Series Welding Tables.
US281015.XD7
Quantity: 1
4' x 4' Basic 8.7 Welding Table Imperial Series (Plasma Nitrided)
US280780
Quantity: 1
System 28 Table Press
US280110.N
Quantity: 4
7" Stop and Clamping Square L (Nitrided)
US280604
Quantity: 6
Universal Basic Pipe Clamp (Burnished)
US280511
Quantity: 10
Short Fast Clamping Bolt (Burnished)
US280420.N
Quantity: 2
9" Universal L Stop (Nitrided)
US160415
Quantity: 8
1/2 x 3-1/8 Steel Flex Stop (Galvanized)
US280543
Quantity: 8
Threaded Bolt Basic M12
US283999
Quantity: 1
6-Piece Accessory-Set
- The materials used are fundamental to the high level of hardness and long service life.
- With a Siegmund® table, you will experience long-term savings, thanks to the high level of precision engineering, as well as the consistent superior quality.
- Side surface of Professional Extreme 8.7 is made of specific basic material S355J2+N incl. plasma nitriding and BAR-coating.
The hardened X7 Steel (the 8.7 Series), is specially made for Siegmund in Germany. This steel is of a considerably higher hardness grade compared to 98% of the welding tables in the market. The only thing harder to our 8.7 series table are our Siegmund 8.8 Series Welding Tables. With the Series 8.7 Siegmund Welding tables, the top plate achieves a hardness of 850 vickers after the Plasma Nitration and the BAR-Treatment. The higher hardness also helps maintain the flatness of the weld table.
Specs and Features
of the System 28, 8.7 Imperial Basic Series Welding Tables
Specs & Features
of the System 28, 8.7 Imperial Series
Welding Tables
Welding Table Specs and Features:
- Overall Tabletop Size: 4' x 4' (48" x 48")
- Borehole Diameter: Ø 28mm (1-1/10")
- Welding Table Series: System 28 Basic Imperial Series
- Welding Table Material Thickness: Approx. 15/16" to 1-1/16"
- Welding Table Material Type and Finish: Professional Extreme 8.7 Hardened Tool Steel, Plasma Nitrided and BAR-Coated
- Table Surface Hardness: 450-850 Vickers
- Official Siegmund Welding Table Part No.: US281015.XD7
- Maximum Weight Load: 5,078 lbs. (Based on Even Distribution)
- Approximate Table Weight: 788 lbs.
- 5/16"x45" chamfer for table mounting.
- Boreholes 28mm (1-1/10"), Boreholes 7/64"x45.
- Radius 1/10" on table edges and 1/4" corners.
- Without side panel.
- Boreholes on the Surface are in a Diagonal Grid.
- M12 thread on 4 sides every 7-7/8".
Welding Table Leg Options
Part Numbers, Specs and Pricing
Welding Table Leg Options
Part Numbers, Specs and Pricing
Siegmund Welding Table Leg Options Chart
| Leg Type | Item No. | Capacity Per Leg | Leg Height | Table Height | Cost Per Leg |
|
1. Standard Leg |
US161856 |
2,200 lbs. |
35" |
36" |
Included |
|
2. Height Adjustable Leg |
US160877.XX |
2,200 lbs. |
22"-38" |
22"-39" |
$85 |
|
3. Leg with Casters and |
US161855 |
440 lbs. |
35" |
36" |
$96 |
|
4. Height Adjustable Leg |
US160879.XX |
440 lbs. |
24"-36" |
25"-37" |
$142 |
Siegmund System 28 Welding Table Leg Options - Full Specifications
1. Standard Siegmund Leg(s)
- Item No.: US161856
- Leg Height: 35"
- Table Height: 36"
- Fine Adjustment: 1-5/16"
- Capacity Per Table Leg: 2,200 lbs.
- Cost Per Leg: $0 (Included with Welding Table as a Standard)
- Cost Per 4 Leg Set: $0 (Included with Welding Table as a Standard)
2. Height Adjustable Siegmund Leg(s)
- Item No.: 160877.XX
- Leg Height (Adjustable): 22" - 38"
- Table Height (Adjustable): 23" - 39"
- Fine Adjustment: 1-5/8"
- Capacity Per Table Leg: 2,200 lbs.
- Cost Per Leg: $85
- Cost Per 4 Leg Set: $340
3. Siegmund Leg(s) with Casters and Locking Brakes
- Item No.: US161855.XX
- Leg Height: 35"
- Table Height: 36"
- Fine Adjustment: 1-3/16"
- Capacity Per Table Leg: 440 lbs.
- Cost Per Leg: $96
- Cost Per 4 Leg Set: $384
4. Height Adjustable Leg(s) with Casters and Locking Brakes
- Item No.: US160879.XX
- Leg Height (Adjustable): 24" - 36"
- Table Height (Adjustable): 25" - 37"
- Fine Adjustment: 1-3/16"
- Capacity Per Table Leg: 440 lbs.
- Cost Per Leg: $142
- Cost Per 4 Leg Set: $568
