Press Brake kit comes un-assembled, you do the final assembly and welding. Designed to fit the Harbor Freight 20 ton hydraulic press Item # 32879 & 60603. Press brake kit includes an adjustable back stop for accurate and repeatable bends.
The top clamping bar is machined out of 4140 material and includes 5 segmented removable sections. 1", 2", 3", 4" and 9.5" long pieces. These segmented blocks can be removed and rearranged to allow bending of restricted areas on a piece of sheet metal or on an already partially formed pieces.
The heavy duty press brake kit has the same quality construction and number of components as the standard press brake kit, however the differences are as follows. The bottom formed channel on the HD press brake kit is cut out of high strength 3/8" thick steel and the bottom "V" die of has a total size of 3.75" wide x 1/4" thick to allow for easier bending of thicker material.
- Max Bending Radius (deg.) 110
- Max Bending Capacity 5/8" plate
- Max Bending Width 19.25"
- Total width of the brake is 22.125" wide
Tools required for assembly, welder, grinder, level, small square.
It Is capable of bending mild steel in the following length and thickness.
- 19" = Full bending width of the bottom die on anything 3/16" or thinner.
- 15" in 1/4"
- 13" in 5/16"
- 11" in 3/8"
- 6" in 1/2"
- 3" in 5/8"
