20 TON Press Brake DIY Builder Kit

Press Brake kit comes unassembled, you do the final assembly and welding.
Designed to fit the Harbor Freight 20 ton hydraulic press Item # 32879 & 60603.
Press brake kit includes an adjustable back stop for accurate and repeatable bends.

  • Max Bending Radius (deg.) 110
  • Max Bending Capacity 3/8" plate
  • Max Bending Width 19.25"
  • Total width of the brake is 22.125" wide

Tools required for assembly: welder, grinder, level, small square.
It Is capable of bending mild steel in the following length and thickness.

  • 19" = Full bending width of the bottom die on anything 1/8" or thinner.
  • 15" in 3/16"
  • 12" in 1/4"
  • 5" in 3/8"
Please provide us a valid shipping address that UPS/FEDEX will deliver to.
NOTE: Shop Press and Bottle Jack are NOT Included
NOTE: The optional centering tabs provided with the press break do not come attached on the fully welded kit.

The DIY 20 ton press makes a great addition to the arbor press plates we sell HERE.


Related Products
from $329.95
from $329.95
Free Shipping Sold out New Backordered
$14.95
$14.95
Free Shipping Sold out New Backordered
$16.95
$16.95
Free Shipping Sold out New Backordered

Customer Reviews

Based on 37 reviews
100%
(37)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
T
Ted Arnold
Perfect

Perfect little tool for the shop, since I generally need to make small pieces, and light duty brackets

C
Charley Reid
Sir

Unless you have free gas, are a certified welder and don't expect to start bending anything when it arrives, opt for the fully welded kit. Press made easy work to help fab up 6 fire extinguisher dollies.

R
Robert Peterson
Owner

Awesome engineering and workmanship. Works great. Thanks

M
Marc Smith
1

Easy to follow directions and works well

E
Erik Hinz
HinzFab

I considered trying to source the parts separately but it wouldve cost twice as much and Id have to do all the designing. I opted for the DIY kit after watching the how-to video. It was straightforward and the included color instructions were clear to follow as well. Ive already used it to make the bends on a push bumper with 10 gauge steel, no issues at all, nice clean bends.
