SWAG 20 TON Press Brake Heavy Duty DIY Builder Kit

Sale price$220.95 Regular price$259.95
15% OFF

Black Friday Sale price Ends in 10d 18h 41m 59s

Choose Options

Desired Configuration: Unwelded
Free shipping
Made in USA
Pay in 4 interest-free installments of $55.23 with Shop Pay

Heavy Duty 20 TON Press Brake DIY Builder Kit


Press Brake kit comes unassembled, you do the final assembly and welding.
Designed to fit the Harbor Freight 20 ton hydraulic press Item # 32879, 60603 & 70603. Shop Press is not included. Press brake kit includes an adjustable back stop for accurate and repeatable bends.

The heavy duty press brake kit has the same quality construction and number of components as the standard press brake kit, however the differences are as follows. The bottom formed channel on the HD press brake kit is cut out of high strength 3/8" thick steel and the bottom "V" die of has a total width of 3.75" wide x 1/4" thick to allow for easier bending of thicker material.

  • Max Bending Radius (deg.) 110
  • Max Bending Capacity 5/8" plate
  • Max Bending Width 19.25"
  • Total width of the brake is 22.125" wide

Tools required for assembly, welder, grinder, level, small square.
It is capable of bending mild steel in the following length and thickness.

  • 19" = Full bending width of the bottom die on anything 3/16" or thinner.
  • 15" in 1/4"
  • 13" in 5/16"
  • 11" in 3/8"
  • 6" in 1/2"
  • 3" in 5/8"
Please provide us a valid shipping address that UPS/FEDEX will deliver to.
NOTE: Shop Press and Bottle Jack are NOT Included.

The HD DIY 20 ton press makes a great addition to the arbor press plates we sell HERE.


  • 5 stars: 61 (95%)
  • 4 stars: 2 (3%)
  • 3 stars: 0 (0%)
  • 2 stars: 0 (0%)
  • 1 star: 1 (2%)
D
David Williams
Correction

I purchased a light-duty 20 ton press break after reading the capabilities of the HD break. Therefore I was in error about the light-duty breaks capability. That being said; I think if one is working with 1/4” or less the LD break may be your best choice. If working with thicker plate, get the HD break.

j
joe hernandez
20 ton press brake

Love it easy to assemble even if your a beginner welder.

A
Alessandre De Almeida
Simply is working for what was designed

I did some parts with 4130 steel and bend with high precision and quality, I'm totally satisfied with the product. The parts is very well made and easy to welding.

A
Aaron
Works awesome

Love it

F
F.B.

I just love it. I think it’s a great precision fit item for my press fun to build. I love the weld so it’s great.

N
Noel

Excellent product and fast ship!

D
Deborah Gibbons
Christmas gift

Great customer service
Everything is well made
Since it's a Christmas gift I won't know how well the recipient will like it but I bet he'll love it.

J
Joshua Mittelman
Easy, breezy, beautiful bending lines

Never had experience bending plate steel before, needed plates bent and the cost of this brake was well below what a machine shop was going to charge. We got perfect bends in less than an hour after opening the box. It's such a simple tool to use, kicking ourselves for not buying one sooner!

Joshua,

Very glad to hear that the Press Brake worked for your application!

Please don't hesitate to reach out to us if any questions come up.

Thank you,
SWAG Off Road

B
Brian Thornton
Great Product, Fast Shipping

Great product, great price, fast shipping. Order came in 2 seperate packages. The instructions worked well, and the Press brake is impressive!! Thanks Swag!!

j
jorge munoz

i order this kit and i decided to pay 150 to get it welded because i don’t have time to do it, so the kit came today and I noticed that it was only part of the kit, so I pay 150 just to weld one little piece of a 1/4 inch angle in to the 3/8 steel chanel, I make a big big mistake and I still need to order the rest of this kit. you guys need to know what are you ordering and what are you paying for, definitely, I don’t recommend to pay to get this kit welded,do it yourself

Jorge,

Thank you for your order.

I do apologize for the confusion, we ship our brakes in two separate boxes to keep the shipping weight down and it looks like only one of the two boxes has been delivered so far. Though we always ship both halves of the brake at the same time, for whatever reason, it is quite common for FedEx to deliver one box a day or two before the other. It appears that you have only received the bottom assembly and your Brake's top assembly is still in transit. I just pulled up your tracking info and it appears the rest of your order is out for delivery as of this afternoon. You will have the rest of your brake by this evening. You can track the package by clicking on the primary tracking number that we emailed over with the original shipping notification, scrolling down on the FedEx webpage a bit, and there will be a second tracking number that is labelled 'In Transit.' Clicking that tracking number will show you the status of your other package.

I do apologize for any inconvenience this delay may have caused you.

Don't hesitate to reach out to us directly if you have any other questions.

Thank you,
SWAG Off Road

J
John Warren
20 ton press break DYI

Very well made, super heavy duty and easy to assemble and weld up..

T
Timothy

The top die that was delivered to me was all one piece .. not finger dies. And not removable.
It may have been because I ordered mine with the option to have the vendor weld it ??
I’m not sure.
It will suit my needs tho so I have no problem with that… but to anyone ordering one of these, it might pay to research it.

R
Ricky

It works. Hard to beat for the money. I wish it came with the extra angle pieces to shrink the bottom die

B
Brandon

Easy to build, plenty strong, bends some pretty thick plate with easy. Kind of wish I got the finger version for some more complex bends, if on the fence, get the fingers.

T
Trace Stanley
20 ton heavy duty brake

Works perfect. Just take your time assembling

R
Rhodes Welding Repairs & Fabrication
Owner

Just recently purchased this heavy duty 20 ton finger brake for my fab shop. Would recommend it to anyone needing to make an addition to their shop. Fast delivery, good instructions on assembly, and reasonable price. Does just as advertised.

S
Steve Simon
Owner

Quality product, deliver quickly. Assembly was well documented and straight forward. I'm a very happy customer!

C
Cody
Mr

Awesome press, easy to build from the kit, works great.

D
Dennis Patrick
Retired

Quality, Quality....all pieces are made with precision making assembly easy. Ive used this for bending numerous thicknesses of steel with no issues and the outcome perfect. I added a series of different sizes of angle iron to bend smaller pieces and it works great. Well worth the money.

C
Chris
cnstaco

Easy to put together. I tested it with some 3/8 plate and it bent 90* no problem. Thumbs up

S
Steven Bentley
So glad I bought this brake kit

I knew I needed a brake for bending metal plate etc for some projects I had coming up. Where possible I like to make things myself and considered making a brake, but Im so glad I got this kit from Swag. Such high quality and so easy to put together. I just taught myself to weld for these upcoming projects so building this brake was the first real project I welded together. The parts are cut perfectly and made putting it all together really simple. Thats actually why I decided to go with Swag instead of fabricating it myself. I realized to get anywhere near the same quality of construction and effectiveness Id have to spend a lot on materials etc. This kit made it simple and saved me a ton of time. Maybe even 20 tons of time (lol). Great brake that works really well. Love it.

j
joe
Business owner

This is the 2nd press brake kit I bought. I needed an economical way to bend 3/8 to 90 deg for mounting flat beds on pickup trucks. this tool does this job very well and did not break the bank. would recommend.

M
Michael Lucas
100 percent satisfied

Product is awesome. Can't believe I've gone as long as I have without the ability to do quality bends with thick metal. I've used it a bunch in the first week. Brackets for landscaping projects, brackets for my car hauler, latches and re-enforcement for a fence/gate, brackets for furniture, the list goes on. If you've ever been curious about what could be possible with this just get it and you'll find all sorts of reason to have this in your life.

G
Greg Minnick
Facility and Equipment manager

Been a good buy so far. We're bending and braking up to 1/4" steel with no problem.

J
Jake
20T HF heavy duty brake

After watching many videos on press brakes and seeing Jody's assembly and review, I ordered the kit for myself. It came quickly and the parts were cut perfectly for easy assembly. I used my 220V mig and it went together easily and quickly. I am more than happy with it's ability to accurately bend anything I throw under it! Well worth the money.

m
matthew kidby
don't fuck around just buy this brake

bought this brake and I love it well worth the money. seems to be very well made

J
Jacob
Owner

This kit was easy to assemble, and works just as it should. We've just started to play with it, but are finding it so useful already! The fitment and finish of parts are top notch. We had a small hiccup with my order, but the Swag team took care of it immediately and professionally. Very satisfied!

J
Jeffrey May
Very nice kit

This is a very well cut kit. All the pieces fit together perfectly and weld up easily. Highly recommend.

L
Lee Connell
Welder

This press brake works amazing. It is definitely a product every shop should have.
